Haibike ALLMTN 3 Electric Mountain Bike
HAIBIKE ALLMTN 3
ABOUT THE BIKE
Are you looking for a robust eFully that takes on any terrain? Then our new ALLMTN 3 is the perfect all-rounder for you: With 160 mm travel front and rear, burly 4-piston disc brakes from Shimano and the powerful Yamaha PW-X3 drive, this eMTB takes you smoothly over all trails. Thanks to the mixed wheel sizes of 29″ front / 27.5″ rear, you will always enjoy perfect traction and master even the steepest uphills and downhills without a problem.
KEY FEATURES
-
FORK
RockShox 35 Gold RL, Travel: 160mm
-
BATTERY
InTube 720 Wh
-
FRAME MATERIAL
Aluminium
-
DRIVE UNIT
Yamaha PW-X3 System, 85Nm, 25km/h
SPECIFICATIONS
-
-
ENGINE
Yamaha, PW-X3, 250W, 85 Nm
-
DISPLAY
Yamaha, Side Switch, 1.7″ LCD, 7 functions
-
BATTERY
InTube, 720 Wh
-
FORK
RockShox, 35 Gold RL, Air, travel= 160 mm, Aluminium steerer tube 1 1/8″ – 1 1/2″ tapered, 15 x 110mm thru-axle Boost
-
DAMPER
RockShox, Deluxe select, Air, Trunnion Mount
-
CRANK ARM
Haibike Components, The Crank ++, Aluminium
-
BRAKE (FRONT)
Shimano, MT420, 4-piston disc brake
-
BRAKE (REAR)
Shimano, MT420, 4-piston disc brake
-
TUBE
Presta valve
-
RIM
WTB, ST i30 TCS, Double Wall
-
CLAMPING RING
Internal hexagon, 38 mm
-
REAR DERAILLEUR
Shimano, Deore M6100
-
SHIFT LEVER
Shimano, Deore M6100, Trigger switch
-
BOTTOM BRACKET
integrated in the motor
-
SPROCKET
Shimano, M6100, 10 – 51 teeth
-
CHAIN
Shimano, CN-M6100
-
CHAINRING
Steel, 36 teeth
-
CHAIN GUIDE
Nylon directmount
-
BRAKE LEVER
Shimano, MT401, Aluminium,
-
BRAKE DISC (FRONT)
Shimano, RT EM300L, 203 mm
-
BRAKE DISC (REAR)
Shimano, RT30-L, 203 mm
-
TYRE
Maxxis, Minion DHF II, 63-622, 29″ x 2.5″
-
FRONT WHEEL HUB
Shimano, MT400-B, Centerlock
-
REAR WHEEL HUB
Shimano, MT410, Centerlock
-
SPOKES
Sapim, Race, Black
-
HANDLEBAR
Haibike Components, TheBar +++, 780 mm
-
STEM
Haibike Components, TheStem ++, A-head, 31.8 mm
-
HEADSET
Acros, BlockLock, Aluminium
-
SADDLE
Selle Royal, Vivo
-
SEAT POST
Haibike Components, Dropper-Post Remote 34.9, Aluminium, Telescope, 34.9 mm
-
PEDALS
Freeridepedal, Aluminium, with Reflector
-
PERMITTED TOTAL WEIGHT
120.0 kg
-
GEAR SHIFT
Shimano, Nexus
-
TYRE (REAR)
Maxxis, Minion DHR II, 66-584, 27.5″ x 2.6″
-
RIM (REAR)
WTB, ST i35 TCS, double wall
-
-
